DockHub Uno
DockHub Uno
Complete Lift Controller and Gateway included with every configuration
Couldn't load pickup availability
DockHub Uno brings lift control, connectivity, and expandable motor capacity into one system for compatible 120 VAC and 240 VAC single-phase boat lift installations.
Every configuration includes one complete DockHub Uno Lift Controller assembly and one DockHub Gateway. Choose one master board, one master plus one expansion board, or one master plus three expansion boards. The Gateway connects the DockHub app to the Lift Controller, while the Lift Controller handles local commands, motor outputs, and controller inputs at the lift.
Use the DockHub app to operate the lift, view system status, manage settings, and share approved access from one account.
Choose your motor-board configuration
- 1 Board — Master: one master motor board.
- 2 Boards — Master + 1 Expansion: one master and one passive expansion motor board.
- 4 Boards — Master + 3 Expansions: one master and three passive expansion motor boards.
The board count describes the boards installed inside the Lift Controller, not additional standalone controllers. All three configurations include the Lift Controller enclosure, required internal harnesses, Gateway, and DockHub app access.
Motor compatibility
In split or dual motor configuration, each board supports two 240 VAC, single-phase motors rated at 1 HP or less each. In bonded or individual configuration, each board supports one 120 VAC, single-phase motor rated at 1 HP or less, or one 240 VAC, single-phase motor rated at 2 HP or less.
All populated boards inside one Lift Controller must use the same split or bonded configuration. Three-phase motors and hydraulic lifts are not supported by the initial Uno configuration. Confirm every motor nameplate and the complete lift configuration before ordering. Compatibility remains subject to final production electrical validation.
Professional installation required
DockHub Uno controls line-voltage equipment and must be installed by a qualified professional. The installer is responsible for confirming the motors, branch circuit, disconnect, grounding, overcurrent protection, enclosure placement, and site conditions.
Pre-sale availability
Orders are scheduled to begin shipping November 15, 2026, in the order received. This is a shipping-start estimate, not a guaranteed delivery date. Customers may cancel for a full refund before shipment under the current pre-sale policy.
What is included
What is included
Every configuration includes one complete DockHub Uno Lift Controller assembly, one Gateway, one master motor board, the expansion boards and internal harnesses required by the selected configuration, one Uno enclosure, and DockHub app access. The board count describes the boards installed inside the Lift Controller, not additional controllers.
How the system fits together
How the system fits together
The Gateway provides Wi-Fi/cloud connectivity and communicates with the Lift Controller over DockHub's local radio link. Board position 1 is the required master motor board. Passive expansion boards in approved positions 2 through 4 add motor channels without creating separate smart devices or accounts.
Motor compatibility
Motor compatibility
1 Board — Master: up to 2 split-configured motors or 1 bonded-configured motor.
2 Boards — Master + 1 Expansion: up to 4 split-configured motors or 2 bonded-configured motors.
4 Boards — Master + 3 Expansions: up to 8 split-configured motors or 4 bonded-configured motors.
Split configuration supports up to two 240 VAC, single-phase motors rated at 1 HP or less each per board. Bonded configuration supports one 120 VAC, single-phase motor rated at 1 HP or less, or one 240 VAC, single-phase motor rated at 2 HP or less per board.
All populated boards use the same channel configuration. Three-phase motors and hydraulic lifts are not supported by the initial Uno configuration. Confirm every motor nameplate and the complete lift configuration before ordering. Compatibility remains subject to final production electrical validation.
Professional installation required
Professional installation required
DockHub Uno controls line-voltage equipment and must be installed by a qualified professional. The installer is responsible for confirming the motors, branch circuit, disconnect, grounding, overcurrent protection, enclosure placement, and site conditions.
Built for the panel, not the drawer
The numbers an electrician or dock builder asks for before wiring anything.
Wiring and install guideUno · spec rev 2026.09Electrical
- Motor Amp Draw
- 15 AMP / 10 AMPDual motor/ Single motor
- Motor voltage
- 120 / 240 VAC Single-phase lift motorsSingle-phase lift motors
- Switching
- High Power Relays
- Wiring
- Labeled terminal blocks
System
- Gateway
- 1 per kitWi-Fi uplink, local radio to the controller
- Lift controller
- Motor board clusterOwns command handling and safety logic
- Motor boards
- 1 · 2 · 4Position 1 master, positions 2 to 4 expansion
Software
- App
- iOS · Android · Web
- Access
- Owner + guestsShareable, revocable, timed
- Updates
- Over the air
- Fees
- None requiredOptional add-ons only
Install
- Typical time
- 30 min
- Enclosure
- Weather-rated, room to routeLabeled terminals, real working space
From your phone to the motor
Every command takes the same route. Select a stage to see what it does.
Operate the lift, check status, manage settings and share approved access. Guests get their own login, so nobody trades remotes.
Operate the lift, check status, manage settings and share approved access. Guests get their own login, so nobody trades remotes.
Routes each command to the right gateway, records device status and sends notifications when something needs attention.
Provides the system's Wi-Fi and cloud connection, then talks to the lift controller over a local radio link. Mounts indoors, not at the dock.
Owns command handling. Holds the safety logic, runs digital auto-stop and drives the motor-board cluster.
Board position 1 is the master. Passive expansion boards occupy positions 2 through 4, and every populated board uses the same channel configuration.
